Description

Customize This Kit Now!

Fits

Year	Make	Model
2020 - 2022	Ford	F250/F350 Super Duty w/ 6.7L Powerstroke

Upgrade your new Super Duty with the reliable BDS 4 - link conversion system. It's a huge improvement over factory stamped steel radius arms, offering better handling, stability, strength, and caster control during wheel travel. The full - length 4' ProRide diesel - specific coil springs add height, paired with BDS NX2 series gas shocks for a smooth ride on any terrain and outstanding performance.

Part Number: BDS1567H

Features

• Diesel Specific
• Replacement rear lift blocks for a level stance
• Pro - Ride coil springs
• Sway bar drop brackets
• Brake line relocation brackets
• Bump stop extensions to limit suspension compression
• High - strength black e - coated u - bolts
• Pitman arm & track bar bracket to correct steering angles and recenter the front axle
• 4 - link conversion for enhanced strength and handling
• Fits up to 37' Tires (Minor trimming may be needed)

Tire & Wheel Combinations:

• 37 x 12.50 w/ 17 x 9 and 4.5' - 5'
• 37 x 12.50 w/ 18 x 9 and 4.5' - 5'
• 37 x 12.50 w/ 20 x 9 and 4.5' - 5'

Notes

• If your vehicle has a 2 - piece rear driveshaft, a carrier bearing drop kit may be needed to avoid driveline vibrations
• You need to remove the factory leaf spring block. The actual lift may vary based on the factory block's height
• You'll need a torque wrench capable of 405 ft - lbs for installation
• Tremor models won't reach the full advertised lift height due to their taller factory ride height. The final height will be the same as standard models
• If installed on a truck with a top - mounted overload spring and an overload spacer block taller than 1 - 1/8', UBT4027 (Qty: 4) are required

Installation

• Click Here For Installation Instructions
• Difficulty: 4 (1 = easiest, 5 = complicated)

Warranty

• Supplemental Drivetrain Limited Protection - 5 Year/60,000 Miles on Ford, Nissan, & Toyota vehicles and 5 Year/100,000 Miles on Dodge/Ram, GMC, & Jeep vehicles.
• Free protection for BDS customers
• Could save you thousands on possible repairs
• Easy online registration process
• Available for most late - model vehicles

Using the BDS 4 - Link Suspension Lift Kit is a great way to upgrade your 2020 - 2022 Ford F250/F350 Super Duty with a 6.7L Powerstroke engine. To use it, you'll first need to follow the installation instructions. Remember, you'll need a torque wrench capable of 405 ft - lbs. If your vehicle has a 2 - piece rear driveshaft, you might need a carrier bearing drop kit to avoid vibrations. And don't forget to remove the factory leaf spring block. As for tire and wheel combinations, you can use 37 - inch tires with various wheel sizes as specified. When it comes to maintenance, regularly check the high - strength black e - coated u - bolts, sway bar drop brackets, and brake line relocation brackets for any signs of wear or damage. Also, keep an eye on the bump stop extensions to make sure they're still limiting suspension compression properly. And if you installed it on a truck with a top - mounted overload spring and an overload spacer block taller than 1 - 1/8', check the UBT4027 components. Enjoy the smooth ride and enhanced handling this kit provides on any terrain!
